3-pcs female thread union 22 x 1″
3-pcs female thread union in the <A> Press Inox 316L range from Conex Bänninger
Product Code
PS26340G0220800
Size
22 x 1"
Application
Cooling Systems, Heating Systems, Hot And Cold Water
Installation Type
Press
Specification
Overview
Product Code
PS26340G0220800
Size
22 x 1"
Application
Cooling Systems, Heating Systems, Hot And Cold Water
Bag Quantity
5
Maximum Operating Pressure (Bar)
16 Bar
Maximum Operating Pressure (kPa)
1600 kPa
Maximum Operating Pressure (PSI)
232 PSI
Materials
Fitting Material
Stainless Steel
O-Ring/Seal Material
EPDM
Dimensions (mm)
L
95.5
Z
54.5
S1
36
S2
39
Installation
＜A＞ Press Inox Installation Sequence
