Barrel Nipple 1/2 x 120mm
Barrel Nipple in the Series 8000 range from Conex Bänninger
Product Code
8530 004120000
Size
1/2 x 120mm
Application
Gas, Heating Systems, Solar And Renewables
Installation Type
Threaded
Specification
Overview
Product Code
8530 004120000
Size
1/2 x 120mm
Application
Gas, Heating Systems, Solar And Renewables
Bag Quantity
10
Operating Temperature Range
-20°C to 225°C
Maximum Operating Pressure (Bar)
25 Bar
Maximum Operating Pressure (kPa)
2500 kPa
Maximum Operating Pressure (PSI)
362 PSI
Materials
Fitting Material
Yellow Brass
Dimensions (mm)
a
120
Find the right system for the job
Need help finding the right system for the job?
Enquire
Series 8000
Barrel Nipple 1/2 x 120mm
