Female Straight Union Connector 22 x 3/4″
Female Straight Union Connector in the >B< Press Solar range from Conex Bänninger
Product Code
PH4330G0220600
Size
22 x 3/4"
Application
Heating Systems, Solar And Renewables
Installation Type
Press
Specification
Overview
Product Code
PH4330G0220600
Size
22 x 3/4"
Application
Heating Systems, Solar And Renewables
Bag Quantity
2
Operating Temperature Range
-20°C to 230°C
Maximum Operating Pressure (Bar)
10 Bar
Maximum Operating Pressure (kPa)
1000 kPa
Maximum Operating Pressure (PSI)
145 PSI
Materials
Fitting Material
Red Brass
O-Ring/Seal Material
FKM
Dimensions (mm)
L
71.5
Z
31
S1
36.5
S2
36
