Fitting Reducer 42 x 28mm
Fitting Reducer in the >B< Press Carbon range from Conex Bänninger
Product Code
PC5243 0422800
Size
42 x 28mm
Application
Cooling Systems, Heating Systems
Installation Type
Press
Specification
Overview
Product Code
PC5243 0422800
Size
42 x 28mm
Application
Cooling Systems, Heating Systems
Bag Quantity
1
Operating Temperature Range
-35°C to 110°C
Maximum Operating Pressure (Bar)
16 Bar
Maximum Operating Pressure (kPa)
1600 kPa
Maximum Operating Pressure (PSI)
232 PSI
Materials
Fitting Material
Carbon Steel
O-Ring/Seal Material
EPDM
Dimensions (mm)
L
82
L1
36
L2
58
L3
42
