Male Straight Union Connector 35 x 1 1/4″
Male Straight Union Connector in the >B< Press Inox range from Conex Bänninger
Product Code
PS4331G0351000
Size
35 x 1 1/4"
Application
Hot And Cold Water
Installation Type
Press
Specification
Overview
Product Code
PS4331G0351000
Size
35 x 1 1/4"
Application
Hot And Cold Water
Bag Quantity
1
Operating Temperature Range
-35°C to 110°C
Maximum Operating Pressure (Bar)
16 Bar
Maximum Operating Pressure (kPa)
1600 kPa
Maximum Operating Pressure (PSI)
232 PSI
Materials
Fitting Material
Stainless Steel
O-Ring/Seal Material
EPDM
Dimensions (mm)
L
114
Z
85
S1
48
S2
43
Installation
＞B＜ Press Inox Installation Sequence
