Straight Coupler 18mm
Straight Coupler in the >B< Push range from Conex Bänninger
Product Code
BM8270 0180000
Size
18mm
Application
Cooling Systems, Hot And Cold Water
Installation Type
Push
Specification
Overview
Product Code
BM8270 0180000
Size
18mm
Application
Cooling Systems, Hot And Cold Water
Bag Quantity
10
Operating Temperature Range
-20°C to 95°C
Maximum Operating Pressure (Bar)
16 Bar
Maximum Operating Pressure (kPa)
1600 kPa
Maximum Operating Pressure (PSI)
232 PSI
Materials
Fitting Material
Brass
O-Ring/Seal Material
EPDM
Dimensions (mm)
A
18
B
18
DA
28
DB
28
LA
49
ZA
1
Installation
＞B＜ Push Installation Sequence
