Straight Female Connector 22 x 3/4″
Female Straight Connector in the >B< Press Carbon range from Conex Bänninger
Product Code
PC4270G0220600
Size
22 x 3/4"
Application
Cooling Systems, Heating Systems
Installation Type
Press
Specification
Overview
Product Code
PC4270G0220600
Size
22 x 3/4"
Application
Cooling Systems, Heating Systems
Bag Quantity
5
Operating Temperature Range
-35°C to 110°C
Maximum Operating Pressure (Bar)
16 Bar
Maximum Operating Pressure (kPa)
1600 kPa
Maximum Operating Pressure (PSI)
232 PSI
Materials
Fitting Material
Carbon Steel
O-Ring/Seal Material
EPDM
Dimensions (mm)
L
57
L1
16
Z
18
S
28
