Straight Female Connector 28 x 1″
Straight Female Connector in the >B< Push range from Conex Bänninger
Product Code
BM8270G0280800
Size
28 x 1"
Application
Cooling Systems, Hot And Cold Water
Installation Type
Push
Specification
Overview
Product Code
BM8270G0280800
Size
28 x 1"
Application
Cooling Systems, Hot And Cold Water
Bag Quantity
5
Operating Temperature Range
-20°C to 95°C
Maximum Operating Pressure (Bar)
16 Bar
Maximum Operating Pressure (kPa)
1600 kPa
Maximum Operating Pressure (PSI)
232 PSI
Materials
Fitting Material
Brass
O-Ring/Seal Material
EPDM
Dimensions (mm)
A
28
B
1"
DA
41
DB
38
LA
54
Installation
＞B＜ Push Installation Sequence
Find the right system for the job
Need help finding the right system for the job?
Enquire
>B< Push
Straight Female Connector 28 x 1″
