Straight Male Connector 18 x 3/4″
Male Straight Connector in the >B< Press Carbon range from Conex Bänninger
Product Code
PC4243G0180600
Size
18 x 3/4"
Application
Cooling Systems, Heating Systems
Installation Type
Press
Specification
Overview
Product Code
PC4243G0180600
Size
18 x 3/4"
Application
Cooling Systems, Heating Systems
Bag Quantity
5
Operating Temperature Range
-35°C to 110°C
Maximum Operating Pressure (Bar)
16 Bar
Maximum Operating Pressure (kPa)
1600 kPa
Maximum Operating Pressure (PSI)
232 PSI
Materials
Fitting Material
Carbon Steel
O-Ring/Seal Material
EPDM
Dimensions (mm)
L
58.5
Z
36.5
S
28
Find the right system for the job
Need help finding the right system for the job?
Enquire
>B< Press Carbon
Straight Male Connector 18 x 3/4″
