Tee – Reduced Branch 42 x 28 x 42mm
Tee - Reduced Branch in the >B< Press Carbon range from Conex Bänninger
Product Code
PC5130 0422842
Size
42 x 28 x 42mm
Application
Cooling Systems, Heating Systems
Installation Type
Press
Specification
Overview
Product Code
PC5130 0422842
Size
42 x 28 x 42mm
Application
Cooling Systems, Heating Systems
Bag Quantity
1
Operating Temperature Range
-35°C to 110°C
Maximum Operating Pressure (Bar)
16 Bar
Maximum Operating Pressure (kPa)
1600 kPa
Maximum Operating Pressure (PSI)
232 PSI
Materials
Fitting Material
Carbon Steel
O-Ring/Seal Material
EPDM
Dimensions (mm)
L
120
L1
56
Z
22
Z1
32
Find the right system for the job
Need help finding the right system for the job?
Enquire
>B< Press Carbon
Tee – Reduced Branch 42 x 28 x 42mm
