Tee – Reduced End and Branch 22 x 15 x 15mm
Tee - Reduced End and Branch in the >B< Press range from Conex Bänninger
Product Code
P5130 02215015
Size
22 x 15 x 15mm
Application
Cooling Systems, Heating Systems, Hot And Cold Water
Installation Type
Press
Specification
Overview
Product Code
P5130 02215015
Size
22 x 15 x 15mm
Application
Cooling Systems, Heating Systems, Hot And Cold Water
Bag Quantity
10
Operating Temperature Range
-35°C to 110°C
Maximum Operating Pressure (Bar)
16 Bar
Maximum Operating Pressure (kPa)
1600 kPa
Maximum Operating Pressure (PSI)
232 PSI
Materials
Fitting Material
Copper
O-Ring/Seal Material
EPDM
Dimensions (mm)
L
40
L1
35
L2
43
Z
17
Z1
13
Z2
21
Installation
