Tee with Female Threaded Branch 35 x 1/2 x 35mm
Tee with Female Threaded Branch in the >B< Press Gas range from Conex Bänninger
Product Code
PG4130G0350435
Size
35 x 1/2 x 35mm
Application
Gas, Heating Systems
Installation Type
Press
Specification
Overview
Product Code
PG4130G0350435
Size
35 x 1/2 x 35mm
Application
Gas, Heating Systems
Bag Quantity
1
Operating Temperature Range
-20°C to 70°C
Maximum Operating Pressure (Bar)
5 Bar
Maximum Operating Pressure (kPa)
500 kPa
Maximum Operating Pressure (PSI)
72 PSI
Materials
Fitting Material
Copper x Red Brass
O-Ring/Seal Material
HNBR
Dimensions (mm)
L
105
L1
50
Z
28.5
Z1
33.7
S
32
Installation
＞B＜ Press Gas: Installation Sequence
