90° Elbow 18mm
90° Elbow in the <A> Press Inox 304 range from Conex Bänninger
Product Code
PSND002 0180000
Size
18mm
Application
Heating Systems
Installation Type
Press
Specification
Overview
Product Code
PSND002 0180000
Size
18mm
Application
Heating Systems
Bag Quantity
10
Operating Temperature Range
-35°C to 110°C
Maximum Operating Pressure (Bar)
16 Bar
Maximum Operating Pressure (kPa)
1600 kPa
Maximum Operating Pressure (PSI)
232 PSI
Materials
Fitting Material
Stainless Steel
O-Ring/Seal Material
EPDM
Installation
＜A＞ Press Inox Installation Sequence
