Male Straight Coupler 8 x 1/4″
Male Straight Coupler in the Conex Compression range from Conex Bänninger
Product Code
B0150CO302--
Size
8 x 1/4"
Application
Cooling Systems, Gas, Heating Systems, Hot And Cold Water, Solar And Renewables
Installation Type
Compression
Specification
Overview
Product Code
B0150CO302--
Size
8 x 1/4"
Application
Cooling Systems, Gas, Heating Systems, Hot And Cold Water, Solar And Renewables
Bag Quantity
10
Operating Temperature Range
-20°C to 110°C
Maximum Operating Pressure (Bar)
25 Bar
Maximum Operating Pressure (kPa)
2500 kPa
Maximum Operating Pressure (PSI)
362 PSI
Materials
Fitting Material
DZR Brass
Dimensions (mm)
D
17
A
8
B
1/4"
C
30
Installation
Conex Compression Installation Sequence
