45° Bend 42mm
45° Bend in the >B< Press INOX 316 range from Conex Bänninger
Product Code
PS5041 0420000
Size
42mm
Application
Cooling Systems, Heating Systems, Hot And Cold Water
Installation Type
Press
Specification
Overview
Product Code
PS5041 0420000
Size
42mm
Application
Cooling Systems, Heating Systems, Hot And Cold Water
Bag Quantity
1
Operating Temperature Range
-35°C to 110°C
Maximum Operating Pressure (Bar)
16 Bar
Maximum Operating Pressure (kPa)
1600 kPa
Maximum Operating Pressure (PSI)
232 PSI
Materials
O-Ring/Seal Material
EPDM
Dimensions (mm)
L
70
Z
34
